ChillBooster
ChillBooster: evaporative cooling
Evaporative cooler that works by atomising water into very fine droplets. The droplets evaporate spontaneously, removing heat from the air, which is thus humidified and cooled. The unit uses a paddle pump to pressurise the water, which is then atomised through special spray nozzles.
Product overzicht
ChillBooster is an evaporative cooler used to increase the efficiency of chillers and drycoolers, as well as other appliances.ChillBooster cools the air before it comes into contact with the coil, thus lowering average condensing pressure.ChillBooster atomises water into very fine droplets that evaporate spontaneously, cooling the air.
The coil is thus cooled by a flow of colder air and droplets of water, allowing more favourable operating conditions.This allows liquid coolers and condensers to deliver their rated capacity even during the hotter periods of the year, which often coincide with operation at maximum load. All without costly system oversizing.
- Very low energy consumption
ChillBooster has extremely low power consumption: a system for drycoolers with an air flow-rate of 200,000 m3/h atomises 1000 l/h, with power consumption less than 0.7 kW!
- Ideal for retrofits
The IP55 pumping unit and easy-to-install modular system make ChillBooster ideal for retrofits on chillers, drycoolers and liquid coolers.
- Easy to install
The water distribution system uses spray pipes available in various lengths, quick couplings and flexible connection pipes, making ChillBooster easy to install, without requiring special tools or welding equipment.
- Energy saving on chillers and drycoolers through evaporative cooling.
- ChillBooster provides that extra gear to handle peak demand on the hottest days of the year.
Technical data can be found in the download section below.
Need more information?
Download all the relevant material for the ChillBooster.
Alle details betreffende de chillBooster
Projecten
Adiabatische koeling voor uitbreiding datacenter in Eindhoven
STULZ ontwikkelde een custom-made oplossing door middel van het plaatsen van zes containers waarin onder andere de adiabatische koeling is gehuisvest.
Een voordeel van adiabatische koeling is dat het koelvermogen toeneemt bij het stijgen van de buitentemperatuur terwijl dit bij traditionele compressorkoeling, juist afneemt. Het koelt de lucht voordat deze door de chiller aangezogen wordt. Zo levert 100 liter water ca 69 kW aan afkoeling met maar 0,25 kW aan opgenomen vermogen door de pomp. Dit zorgt ervoor dat het energieverbruik op de warmste dagen van het jaar gereduceerd wordt. Daarnaast is water als koudemiddel volledig milieuvriendelijk in tegenstelling tot de traditionele koudemiddelen.
