Sustainable house

At the edge of one of the most beautiful parts of the Netherlands, the Hoeksche Waard, we have delivered an installation to provide cooling and heating to a former inn dating from 1770 (!). The house was already provided with a cavity wall and a high performance boiler with heating line, and a release system which needs maximum 60 ℃ water at an outside temperature of -10 ℃. However, the gas consumption of about 3500 m³ per year to the beautiful 2.5 centuries old building with a living area of 240 m² was a big cost for the residents and therefore they called for help.

STULZ provided the needed help in the form of a cooling and heating installation. The residents chose a hybrid heat pump from Mitsubishi Heavy Industries (FDCW 60 VNX-A with an HSB 60 and RC-HY40, and the RMU40 room thermostat). The heat pump will reduce gas consumption to about 1300 m³ with equal use (that's a saving of 2200 m³). With today's prices, about €1.98 per m³ and €0.47/kW, that saving is about €1325,- which means that after deducting the subsidy (€2700) for the heat pump, there is a Return On Investment period of about 3 to 4 years on this installation!

The savings will be slightly larger because in the bedrooms and office on the second floor there are two Multi Split systems installed consisting of two SCM 40 ZS-S outdoor units, three SRK 20 ZSX-W wall unit and one SRF 25 ZMX-S floor unit. In the summer, of course, cooling can be provided by the air conditioning in the bedrooms and office. The heating of shower water with this system is still controlled from the boiler.

Hydrolution

Mitsubishi Heavy Industries Thermal Systems air to water heat pump is a complete modern system for heating, cooling and producing hot sanitary water for houses, offering effective energy saving and reducing carbon dioxide emission.
